5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel

5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel
5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel 5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel 5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel 5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel

Hình ảnh lớn :  5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel

Thông tin chi tiết sản phẩm:
Place of Origin: China
Hàng hiệu: Jiuna
Chứng nhận: ROHS
Model Number: Diameter5 mm
Thanh toán:
Minimum Order Quantity: 1000 meters
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability: 96.000 meters per Month
Chi tiết sản phẩm
vật tư: PU loại: Đai tròn PU
color: orange áp dụng nhiệt độ: -35 ℃ ~ 100 ℃
bề mặt: trơn tru Độ cứng: 85A-90A
chiều dài: 30m / cuộn
Điểm nổi bật:

dây đai tròn pu

,

dây đai tròn màu xanh lá cây

,

dây đai polyurethane tròn 5mm Dia



5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel

Items NO.Φ

Least radius of gyration

Stretching rate

Maximum tensile rate

Hardness

Length of rolled

DIA(mm)

 In

mm

  %

Kg

Lbs

Shore( A)

Length of rolled

2mm

0.79

20

1.5-3%

0.3

0.7

95

400

2.5mm

0.87

22

1.5-3%

0.4

0.9

95

400

3mm

0.98

25

1.5-3%

0.7

1.6

90

400

3.5mm

1.18

30

1.5-3%

0.95

2.1

90

400

4mm

1.38

35

1.5-3%

1.2

2.7

90

200

5mm

1.57

40

1.5-3%

2.0

4.3

90

100

6mm

1.97

50

1.5-3%

3.2

7.0

90

100

7mm

2.17

55

1.5-3%

4.1

9.0

90

100

8mm

2.56

65

1.5-3%

5.0

11.0

90

100

9mm

2.95

75

1.5-3%

6.8

15.0

90

50

10mm

2.95

75

1.5-3%

7.7

17.0

90

50

12mm

3.94

100

1.5-3%

12.2

27.0

90

30

15mm

4.72

120

1.5-3%

17.7

39.0

90

30

18mm

5.71

145

1.5-3%

25.4

56.0

90

30

20mm

6.30

160

1.5-3%

31.3

69.0

90

30



Details:



(1)Thermoplastic polyurethane material, easy to be melted jointed

(2)Reinforced by Polyester Cord or Steel Cord

(3)Temperature range -35°C - 80°C

(4)Shore A hardness range 80A - 98A

(5)With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics.

Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and

other industries, especially in the ceramic industry, widely used in the facilities line the glaze,

 polishing lines, and transmission line.

(6)Round Belt:

Round Belt Dia. is from 2mm to 30mm

Features:

Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set

Application:

Newspaper conveying,
Packing machines,
Ceramic and stoneware processing plants,
Floor and roof tiles conveying,
Wood Working machineries,
Textile machines,
Paper industry machines,
Food grading machines, other food processing machines.

5mm PU Belt Transmission Urethane Belting Good Resistance To Fuel 0
