M-8 ,Z-10 type PU Conducting Bar Polyurethane V Belt for Processing Industry 75shore A

Trung Quốc Wuxi Jiunai Polyurethane Products Co., Ltd Chứng chỉ
Trung Quốc Wuxi Jiunai Polyurethane Products Co., Ltd Chứng chỉ
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

Tôi trò chuyện trực tuyến bây giờ

M-8 ,Z-10 type PU Conducting Bar Polyurethane V Belt for Processing Industry 75shore A

M-8 ,Z-10 type PU Conducting Bar Polyurethane V Belt for Processing Industry 75shore A
M-8 ,Z-10 type PU Conducting Bar Polyurethane V Belt for Processing Industry 75shore A M-8 ,Z-10 type PU Conducting Bar Polyurethane V Belt for Processing Industry 75shore A M-8 ,Z-10 type PU Conducting Bar Polyurethane V Belt for Processing Industry 75shore A

Hình ảnh lớn :  M-8 ,Z-10 type PU Conducting Bar Polyurethane V Belt for Processing Industry 75shore A

Thông tin chi tiết sản phẩm:
Place of Origin: China
Hàng hiệu: Jiuna
Chứng nhận: ROHS
Model Number: A-13 / B-17 / C-22
Hardness: 90 shore A
Length: 30 meter /rolls
Thanh toán:
Minimum Order Quantity: 600 Meter
Packaging Details: Normal packing. Inner packing is plastic film .outer packing is carton . Or according to customers'
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability: 96.000 meters per Month
export port: shanghai
Factory: Wuxi City
Chi tiết sản phẩm
Điểm nổi bật:

green round belt

,

pu extruded belt

M-8 ,Z-10 type  Conducting Bar PU polyurethane V-belt for Processing Industry



PU V-section belt characteristics

1.excellent elasticity and damping characteristics

2.High tensile strength

3.With smooth surface v-belts

4.Color :red ,white

5.Hardness 90 shore A

6.Available with or without reinforced cord .

7.Replacement for conventional rubber V-belts , but more wear-resisting and can welding.

                                                         M-8 ,Z-10 type PU Conducting Bar Polyurethane V Belt for Processing Industry 75shore A 0

Product Technical Parameters :

Specification

X(mm)

Y(mm)

Z(mm)

M/rolls

reinforced

arabesquitic

A

13

8

3.5

30

·

·

B

17

11

3.5

30

·

·

C

22

14

3.5

30

·

·

D

32

19

3.5

30

·

·

M

8

4



50





Z

10

5

3.5

50

·

·





Polyurethane V-Belt Application :

1.       Widely used in textile ,

2.       printing and packing machine ,

3.       food & beverage processing,

4.       wood processing ,

5.       paper processing ,

6.       electronic ,

7.       post service ,

8.       tobacco transmission line ,

9.       Wall floor tile conveying industrial line ,

10.    ceramic industry line or polishing line .





Products introduction

We offer a complete line of Polyester and Polyurethane V-belts for use in ceramic industrial  transmissions and a wide variety of conveyor applications. V-belts run in single or multiple lines side by side. These belts ensure proper alignment, reduced slippage and are perfect for the transport of products up and down an incline such as boxing, packaging materials, aggregates, glass, tiles and many other products. The very elastic and flexible material PU 85 A ~90 A in red is particularly suitable for lead in conveyors and vertical shafts.

In addition , We are able to tailor Round and V-belts of different lengths and diameters - within a few days and with high quality.



Service commitment

 “Quality for keeping going ,Credit to win the world”
