Green Round Belts Polyurethane Drive Belt Transmission ROHS Approved

Trung Quốc Wuxi Jiunai Polyurethane Products Co., Ltd Chứng chỉ
Trung Quốc Wuxi Jiunai Polyurethane Products Co., Ltd Chứng chỉ
Customer satisfaction products , good service !

—— Mr. Alcioni possamai

we are very impressed with the quality of the belts you produced.

—— Mr.Mike

your products are very popular in my markets.

—— Mr. jone

Tôi trò chuyện trực tuyến bây giờ

Green Round Belts Polyurethane Drive Belt Transmission ROHS Approved

Green Round Belts Polyurethane Drive Belt Transmission ROHS Approved
Green Round Belts Polyurethane Drive Belt Transmission ROHS Approved Green Round Belts Polyurethane Drive Belt Transmission ROHS Approved Green Round Belts Polyurethane Drive Belt Transmission ROHS Approved Green Round Belts Polyurethane Drive Belt Transmission ROHS Approved

Hình ảnh lớn :  Green Round Belts Polyurethane Drive Belt Transmission ROHS Approved

Thông tin chi tiết sản phẩm:
Place of Origin: china
Hàng hiệu: jiuna
Chứng nhận: ROHS
Model Number: Diameter 2mm-20mm
Thanh toán:
Minimum Order Quantity: 10 rolls
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100.000 meters per Month
Chi tiết sản phẩm
bề mặt: khó khăn màu sắc: màu xanh lá
đường kính: 6mm Loại: Đai tròn PU
vật tư: PU chiều dài: 100m / cuộn
Điểm nổi bật:

đai tròn pu

,

đai tròn màu xanh lá cây

,

đai truyền động Polyurethane được rohs phê duyệt



Green Round Belts Polyurethane Drive Belt Transmission ROHS Approved

Specifications

PU round belt
hardness:80A-95A
color: orange or green
Dia:2mm-20mm
Stretching rate:1.5-3%

PU round belt
hardness:80A-95A
color: orange or green(  smooth round belt and rough round belt)

Dia:2mm-20mm
Stretching rate:1.5-3%

Material: polyurethane

(1) Thermoplastic polyurethane material, easy to be melted jointed
(2) Reinforced by Polyester Cord or Steel Cord
(3) Temperature range -35°C - +75°C
(4) Shore A hardness range 45A - 90A
(5) With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics. Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and other industries, especially in the ceramic industry, widely used in the facilities line the glaze, polishing lines, and transmission line.





Items No. φ least radius of gyration stretch rate Maximum tensile rate Hardness length of rolled

Dia.

(mm)

In mm Stretching rate Kg Lbs

Hardness

(A)

Roll

(m)

2mm 0.79 20 1.5-3% 0.3 0.7 90 400 m
3mm 0.98 25 1.5-3% 0.7 1.6 90 400 m
4mm 1.38 35 1.5-3% 1.2 2.7 85 200 m
15mm 4.72 120 1.5-3% 17.7 39.0 85 30   m
18mm 5.71 145 1.5-3% 25.4 56.0 85 30   m
20mm 6.30 160 1.5-3% 31.3 69.0 85 30   m

Products introduction:

Urethane round belts are elastomeric belts for power transmission application.

Having most metric sizes (2mm to 20mm) and standard O-ring sizes.

Polyether and Polyurethane round belts have best resilience of any elastic material.

Polyester product has good wear resistance, its wear resistance is 3.5 times of common plastic

and rubber.

Adopt the new polyurethane raw materials imported from Taiwan, with the most advanced equipment and technology, interface and firm, PU round belt surface spectral surface and rough surface, PU round belt main transmission and transmission line effect, wear-resisting, non-toxic, corrosion resistance, resistance to bend, can fast welding, etc. Widely used in construction ceramics, tiles, packaging machinery, paper making, printing, textile printing and dyeing, glass, industrial sewing machines, food and other industries.
Specification: 2mm 3mm 4mm 5mm  6mm 7mm 8mm 10mm 12mm 15mm 18mm
Color:Red/Green/Orange
Matrial: PU
Style: Smooth/Rough
Advantages:
1.transmission and transmission line effect,
2.wear-resisting, non-toxic, corrosion resistance
3.resistance to bend, can fast welding.
Application: Widely used in construction ceramics, tiles, packaging machinery, paper making, printing, textile printing and dyeing, glass, industrial sewing machines, food and other industries.

Service commitment:

“ Quality for keeping going ,Credit to win the world”
