Good Weatherability And High Impact Resistance Green Polyurethane Round Belt For Industrial

Good Weatherability And High Impact Resistance Green Polyurethane Round Belt  For Industrial
Good Weatherability And High Impact Resistance Green Polyurethane Round Belt  For Industrial Good Weatherability And High Impact Resistance Green Polyurethane Round Belt  For Industrial Good Weatherability And High Impact Resistance Green Polyurethane Round Belt  For Industrial Good Weatherability And High Impact Resistance Green Polyurethane Round Belt  For Industrial

Hình ảnh lớn :  Good Weatherability And High Impact Resistance Green Polyurethane Round Belt For Industrial

Thông tin chi tiết sản phẩm:
Place of Origin: China
Hàng hiệu: jiuna
Chứng nhận: ROHS
Model Number: Diameter 5mm~15mm
Thanh toán:
Minimum Order Quantity: 10rolls
Packaging Details: Inner packing is plastic film .outer packing is carton .
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: T/T, 50% payment in advance ,50% balance before shipment ; Western Union ; L/C
Supply Ability: 96.000 meters per Month
Chi tiết sản phẩm
màu sắc: màu xanh lá cây hoặc theo yêu cầu của bạn vật tư: PU
lâu dài: 300m / cuộn 200m / cuộn 100m / cuộn độ cứng: 85A-90A
tốc độ kéo: 0,3kg-31,3kg tỷ lệ kéo dài: 1,5% -3%
Điểm nổi bật:

đai tròn pu

,

đai đùn pu

,

đai tròn PU công nghiệp

Features:

Outstanding abrasion resistance
High tensile and tear strength
Resistance to oils, fuels,and oxygen
Good weatherability and high impact resistance
Low compression set

PU Cord Belt Application :


  Packing machines,
 Ceramic and stoneware processing plants,
Floor and roof tiles conveying,
 Wood Working machineries,
Textile machines,
 Paper industry machines,
   Food grading machines, other food processing machines.





Items No. φ least radius of gyration stretch rate Maximum tensile rate Hardness length of rolled

DIA

(mm)

In mm Stretching rate Kg Lbs

Hardness

(A)

Roll

(m)

7mm 2.17 55 1.5-3% 4.1 9.0 85 100
8mm 2.56 65 1.5-3% 5.0 11.0 85 100
9mm 2.95 75 1.5-3% 6.8 15.0 85 50
10mm 2.95 75 1.5-3% 7.7 17.0 85 50
12mm 3.94 100 1.5-3% 12.2 27.0 85 30
15mm 4.72 120 1.5-3% 17.7 39.0 85 30
18mm 5.71 145 1.5-3% 25.4 56.0 85 30
20mm 6.30 160 1.5-3% 31.3 69.0 85 30




Good Weatherability And High Impact Resistance Green Polyurethane Round Belt  For Industrial 0
