Wide Application Temperature Transmission Urethane Belt For Machine

Wide Application Temperature Transmission Urethane Belt For Machine
Wide Application Temperature Transmission Urethane Belt For Machine Wide Application Temperature Transmission Urethane Belt For Machine Wide Application Temperature Transmission Urethane Belt For Machine Wide Application Temperature Transmission Urethane Belt For Machine

Hình ảnh lớn :  Wide Application Temperature Transmission Urethane Belt For Machine

Thông tin chi tiết sản phẩm:
Place of Origin: china
Hàng hiệu: jiuna
Chứng nhận: ROHS
Model Number: Diameter 2mm-20mm
Thanh toán:
Minimum Order Quantity: 10 rolls
Packaging Details: Inner packing is plastic film .outer packing is carton
Delivery Time: Within 5 working days After receipt of your deposit
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 100.000 meters per Month
Chi tiết sản phẩm
hardness: 85A màu sắc: màu xanh lá
tỷ lệ kéo dài: 1,5-3% tốc độ kéo: 0,7 lbs-69 lbs
vật tư: PU chiều dài: 400m / cuộn 300m / cuộn 200m / cuộn 100m / cuộn 30m / cuộn
Mã HS: 39269010 Khả năng sản xuất: Nguồn cung dài hạn
Điểm nổi bật:

đai tròn pu

,

đai đùn pu

,

đai tròn đường kính 12mm polyurethane



Wide Application Temperature Transmission Urethane Belt For Machine





Detailed Product Description



Industrial 12mm Polyurethane Round Belt Orange or Green for Packing Machine



Details:
(1)Thermoplastic polyurethane material, easy to be melted jointed
(2)Reinforced by Polyester Cord or Steel Cord
(3)Temperature range -35°C - 80°C
(4)Shore A hardness range 80A - 98A
(5)With excellent resistance to flex, abrasion resistance, easy jointed and other characteristics. Widely used in textile, packaging, printing, machinery, electronic, glass, chemicals, ceramics and other industries, especially in the ceramic industry, widely used in the facilities line the glaze, polishing lines, and transmission line.
(6)Round Belt:
Round Belt Dia. is from 2mm to20mm
Smooth Belt with good surface finish; Rough belt with even surface roughness. They are used widely.
PU Round belt with reinforcement



polyurethane Round Belts Feature:



         1.       With excellent bend resistant

         2.       abrasion/wear resistant

         3.       easily connected

         4.       it's not easy to be broken at low temperature

         5.       fuel and oil resistant

         6.       anti static





polyurethane round belt Application :



                                     1.       Widely used in textile

                                     2.       printing and packing machine

                                     3.       food & beverage processing

                                     4.       wood processing

                                     5.       paper processing

                                     6.       electronic

                                     7.       post service

                                     8.       tobacco transmission line

                                     9.       Wall floor tile conveying industrial line

                                    10.      Ceramic industry line or polishing line







Items No. φ least radius of gyration stretch rate Maximum tensile rate Hardness length of rolled

Dia.

(mm)

In mm Stretching rate Kg Lbs

Hardness

(A)

Roll

(m)

2mm 0.79 20 1.5-3% 0.3 0.7 90 A 400
3mm 0.98 25 1.5-3% 0.7 1.6 90 A 400
4mm 1.38 35 1.5-3% 1.2 2.7 85 A  200
15mm 4.72 120 1.5-3% 17.7 39.0 85 A  30
18mm 5.71 145 1.5-3% 25.4 56.0 85 A  30
20mm 6.30 160 1.5-3% 31.3 69.0 85 A  30





Products introduction:





Urethane round belts are elastomeric belts for power transmission application.

Having most metric sizes (2mm to 20mm) and standard O-ring sizes.

Polyether and Polyurethane round belts have best resilience of any elastic material.

Polyester product has good wear resistance, its wear resistance is 3.5 times

of common plastic and rubber.





Service commitment:

“Quality for keeping going ,Credit to win the world”



Wide Application Temperature Transmission Urethane Belt For Machine 0Wide Application Temperature Transmission Urethane Belt For Machine 1Wide Application Temperature Transmission Urethane Belt For Machine 2



Wide Application Temperature Transmission Urethane Belt For Machine 3
